Archer OpTx(米)

アクロマートレンズ


アクロマートレンズ(正/凸)(負/凹)両方取り扱っています。
下図に記載の品番は全て標準品です。
セメント接合タイプ/エアスペースタイプの両タイプが御提供可能です。

Positive (正/凸) Achromats
 品番 直径(mm) EFL (mm) 基板1 基板2 R1 R2 R3 Tc(mm) Te(mm)
ADP-5-7.5A 5 7.5 BK7 SF5 5.100 -3.100 -7.100 3.00 1.08
ADP-5-7.5B SF6 5.100 -3.500 -6.329
ADP-5-10A 5 10 BK7 SF5 6.329 -4.328 -11.350 2.50 1.19
ADP-5-10B SF6 6.000 -5.100 -10.610
ADP-5-15A 5 15 BK7 SF5 9.247 -6.481 -18.408 2.00 1.15
ADP-5-15B SF6 8.770 -7.360 -16.596
ADP-6-10A 6 10 BK7 SF5 6.329 -4.328 -11.350 3.00 1.04
ADP-6-10B SF6 6.000 -5.100 -10.568
ADP-6.35-12.7A 6.35 12.7 BK7 SF5 8.00 -5.754 -15.136 2.50 0.89
ADP-6.35-12.7B SF6 7.180 -6.481 -14.872
ADP-6.35-15A 6.35 15 BK7 SF5 9.350 -6.750 -18.408 2.50 1.15
ADP-6.35-15B SF6 8.770 -7.570 -16.810
ADP-8-10A 8 10 BK7 SF5 6.087 -5.100 -12.460 4.50 1.07
ADP-8-10B SF6 6.200 -5.100 -9.761
ADP-8-16A 8 16 BK7 SF5 9.957 -7.410 -19.953 2.80 0.79
ADP-8-16B SF6 9.072 -8.220 -18.963
ADP-8-20A 8 20 BK7 SF5 12.460 -8.954 -24.720 2.80 1.20
ADP-8-20B SF6 11.690 -10.069 -22.490
ADP-12.7-19A 12.7 19 BK7 SF5 11.900 -9.072 -23.000 6.00 1.57
ADP-12.7-19B SF6 11.110 -9.900 -21.150
ADP-12.7-25A 12.7 25 BK7 SF5 15.305 -11.565 -32.180 5.00 1.72
ADP-12.7-25B SF6 14.388 -12.710 -28.630
ADP-12.7-30A 12.7 30 BK7 SF5 18.408 -13.737 -38.756 4.00 1.30
ADP-12.7-30B SF6 17.520 -15.305 -34.430
ADP-12.7-50A 12.7 50 BK7 SF5 30.620 -22.220 -64.880 2.80 1.21
ADP-12.7-50B SF6 26.086 -26.900 -72.000
ADP-12.7-75A 12.7 75 BK7 SF5 45.600 -33.327 -99.303 2.50 1.45
ADP-12.7-75B SF6 42.332 -37.330 -90.000
ADP-25.4-30A 25.4 30 BK7 SF5 18.707 -15.668 -36.600 13.50 2.04
ADP-25.4-30B SF6 17.600 -16.457 -33.327
ADP-25.4-35A 25.4 35 BK7 SF5 21.710 -17.539 -44.284 12.00 2.46
ADP-25.4-35B SF6 20.304 -18.707 -40.000
ADP-25.4-40A 25.4 40 BK7 SF5 24.830 -19.470 -50.700 10.50 2.29
ADP-25.4-40B SF6 23.170 -21.100 -46.340
ADP-25.4-45A 25.4 45 BK7 SF5 27.774 -21.579 -58.080 9.50 2.29
ADP-25.4-45B SF6 25.940 -23.610 -53.921
ADP-25.4-50A 25.4 50 BK7 SF5 31.000 -23.330 -63.630 9.00 2.52
ADP-25.4-50B SF6 28.840 -25.680 -57.970
ADP-25.4-60A 25.4 60 BK7 SF5 36.961 -27.451 -77.420 8.00 2.64
ADP-25.4-60B SF6 33.327 -31.520 -76.000
ADP-25.4-75A 25.4 75 BK7 SF5 45.710 -34.014 -98.770 7.00 2.74
ADP-25.4-75B SF6 42.613 -38.200 -90.000
ADP-25.4-100A 25.4 100 BK7 SF5 61.800 -44.478 -128.830 6.00 2.83
ADP-25.4-100B SF6 57.654 -51.520 -118.950
ADP-25.4-150A 25.4 150 BK7 SF5 91.150 -66.370 -197.700 5.00 2.88
ADP-25.4-150A SF6 85.900 -76.000 -178.000
ADP-25.4-200A 25.4 200 BK7 SF5 122.180 -90.000 -266.400 4.00 2.44
ADP-25.4-200B SF6 117.760 -98.123 -224.560
ADP-25.4-250A 25.4 250 BK7 SF5 152.400 -111.400 -330.940 4.00 2.74
ADP-25.4-250B SF6 149.970 -118.950 -266.400
ADP-25.4-300A 25.4 300 BK7 SF5 182.410 -133.970 -397.604 3.00 1.95
ADP-25.4-300B SF6 186.210 -138.310 -300.685
ADP-25.4-400A 25.4 400 BK7 SF5 243.800 -177.155 -534.328 3.00 2.21
ADP-25.4-400B SF6 266.400 -174.588 -361.534
ADP-25.4-500A 25.4 500 BK7 SF5 304.580 -220.764 -662.760 3.00 2.37
ADP-25.4-500B SF6 361.534 -205.310 -405.423
ADP-30-50A 30 50 BK7 SF5 30.417 -22.220 -62.705 12.50 2.72
ADP-30-50B SF6 28.252 -24.390 -56.445
ADP-30-80A 30 80 BK7 SF5 48.990 -36.600 -105.350 7.50 1.93
ADP-30-80B SF6 46.340 -41.370 -95.215
ADP-30-100A 30 100 BK7 SF5 61.026 -44.842 -131.726 7.50 3.04
ADP-30-100B SF6 58.080 -50.350 -116.410
ADP-50.8-75A 50.8 75 BK7 SF5 46.340 -37.760 -98.770 21.00 3.60
ADP-50.8-75B SF6 43.188 -40.640 -88.830
ADP-50.8-80A 50.8 80 BK7 SF5 48.600 -40.000 -108.380 19.00 2.73
ADP-50.8-80B SF6 45.600 -43.290 -96.610
ADP-50.8-100A 50.8 100 BK7 SF5 61.800 -47.097 -128.830 17.00 4.10
ADP-50.8-100B SF6 57.654 -51.760 -116.680
ADP-50.8-150A 50.8 150 BK7 SF5 92.900 -68.270 -194.990 11.50 3.06
ADP-50.8-150B SF6 85.512 -75.000 -175.770
ADP-50.8-200A 50.8 200 BK7 SF5 122.180 -90.000 -263.470 9.00 2.67
ADP-50.8-200B SF6 117.760 -98.123 -222.450
ADP-50.8-250A 50.8 250 BK7 SF5 152.400 -111.400 -330.940 8.00 2.93
ADP-50.8-250A SF6 149.970 -118.950 -266.400
ADP-50.8-300A 50.8 300 BK7 SF5 182.410 -133.970 -397.604 7.00 2.79
ADP-50.8-300B SF6 186.210 -138.310 -300.685
ADP-50.8-400A 50.8 400 BK7 SF5 243.800 -177.155 -534.328 6.00 2.84
ADP-50.8-400B SF6 266.400 -174.588 -361.534
ADP-50.8-500A 50.8 500 BK7 SF5 304.580 -220.764 -662.760 6.00 2.53
ADP-50.8-500B SF6 361.534 -205.310 -405.423
ADP-50.8-750A 50.8 750 BK7 SF5 455.000 -330.940 -1000.000 5.00 3.31
ADP-50.8-750B SF6 721.110 -250.750 -455.000
ADP-50.8-1000A 50.8 1000 BK7 SF5 600.320 -442.338 -1367.700 5.00 3.77
ADP-50.8-1000B SF6 1400.000 -275.000 -479.140


Negative (負/凹)Achromats
 品番 直径(mm) EFL (mm) 基板1 基板2 R1 R2 R3 Tc(mm) Te(mm)
ADN-6-9A 6 -9 BK7 SF5 -6.329 5.100 12.067 3.00 1.08
ADN-6-9B SF6 -5.900 5.600 11.109
ADN-8-12A 8 -12 BK7 SF5 -8.465 6.750 15.889 2.50 1.19
ADN-8-12B SF6 -7.790 7.410 14.799
ADN-10-15A 10 -15 BK7 SF5 -10.567 8.465 19.952 2.00 1.15
ADN-10-15B SF6 -9.760 9.459 18.707
ADN-12.7-20A 12.6 -20 BK7 SF5 -15.205 10.519 23.000 3.00 1.04
ADN-12.7-20B SF6 -14.264 11.507 21.149
ADN-12.7-25A 12.6 -25 BK7 SF5 -16.827 12.500 32.179 2.50 0.89
ADN-12.7-25B SF6 -16.110 13.964 28.629
ADN-12.7-30A 12.6 -30 BK7 SF5 -19.498 14.139 38.756 2.50 1.15
ADN-12.7-30 SF6 -18.707 16.239 34.589
ADN-12.7-50A 12.6 -50 BK7 SF5 -31.520 22.489 64.879 4.50 1.07
ADN-12.7-50B SF6 -26.742 27.209 72.000
ADN-25.4-40A 25.3 -40 BK7 SF5 -28.355 21.879 50.699 2.80 0.79
ADN-25.4-40B SF6 -26.060 23.500 47.097
ADN-25.4-50A 25.3 -50 BK7 SF5 -34.014 25.108 63.209 2.80 1.20
ADN-25.4-50B SF6 -31.800 28.049 57.969
ADN-25.4-75A 25.3 -75 BK7 SF5 -45.710 36.000 108.379 6.00 1.57
ADN-25.4-75B SF6 -45.000 40.339 90.000
ADN-25.4-100A 25.3 -100 BK7 SF5 -61.800 45.000 133.969 5.00 1.72
ADN-25.4-100B SF6 -57.654 51.759 122.179
Zemax、Oslo、Code V形式のデータもご提供可能です。
